Below is a description of the Spire Fields for this Import
Please refer the User Manual for more information on how to do imports.
Please take note that sub-assembly components will only appear in the Production Templates if the import file contained subcomponent records. These are not added by Spire automatically when importing.
| Spire 3.12 Fields | Explanation | Example |
| Sequence (Required) | Subassemblies of parent-build components | 1 |
| Parent Sequence (Required) | Parent | 33 Note: If this row is not a subassembly, the Parent Sequence is 0 |
| Default | Default Template checkmark | FALSE = No; TRUE = Yes |
| Warehouse (Required) | Warehouse | 00 |
| Part No. (Required) | Part No | RESCAB30 |
| Description | Description of Part No | Resistance Cable 30 lb. Pink |
| Unit Quantity | Default quantity required | 1 |
| Category | Category assigned to this build | MAN |
| Customer No | Customer No. | A1PAR |
| Priority | Choose Highest to Lowest | To set it to Normal, enter "2". |
| Expected Yield % | Expected yield percentage | 100 |
| Reference number | Default refence number | 1234567 |
| Phase ID | Starting Phase Code | BUILD |
| WIP Account No | GL Account for Work In Progress | 13330 |
| Employee | Employee Code | BARBAR |
| Instructions | Manufacturing Instructions | Fasten the fastener to the handle |
